12V 60W Phase Cut Triac Dimmable LED Driver 24V 36V 48V Waterproof LED Driver

Name: 12V 60W Phase Cut Triac Dimmable LED Driver 24V 36V 48V Waterproof LED Driver
Brand: KSPOWER
Price: 31.20 USD

Buy cheap 12V 60W Phase Cut Triac Dimmable LED Driver 24V 36V 48V Waterproof LED Driver product

Place of Origin : Guangdong, China

Brand Name : KSPOWER

Model Number : KSLP-60W

Certification : UL cUL CE Class 2 Class P ENEC Gs TYPE HL...

MOQ : 2 pieces

Price : $31.20/pieces 2-499 pieces

Warranty(Year) : 5-Year

Lighting solutions service : Lighting and circuitry design

Output Power : 60W

Output Type : PWM

Input Voltage : 100-277V

Output Frequency : 50/60Hz

Output Current : 1.25A-5A

Product Name : 24V 36V 48V 0-10V PWM Resistance Dimming Power Supply

Output : 12V 24V 36V 48V 60W

Application : Street Light, Tunnel Light, Wall Lamp,Spot Light

IP Rate : IP65,IP67

Material : Aluminium Case

Warranty : 5 Years

Output Mode : Pwm Output

Efficiency : ≥ 89%

Type : Constant Voltage

Contact Now

12V 60W Phase Cut Triac Dimmable LED Driver 24V 36V 48V Waterproof LED Driver

Products Description

100V-277VAC to 12V60W Triac Phase cut Dimmable LED Driver 24V 36V 48V 0-10V PWM Resistance Dimming Power Supply

The KSPOWER - LP series 5 in 1 dimmable 60W led driver is one constant voltage solution, single channel, accept universal AC input voltage range from 100V to 277V, output voltage 12Volt 24Volt 36Volt 48Volt optional with greater operating efficiency and higher PFC function. The class p dimming power supply use low profile metal aluminum case, dry and damp, makes the dimmable led driver power solutions for LED strips, LED sign, billboard and landscape lighting. Featuring 2K frequency PWM output and IP67 waterproof environment protection rated for indoor or outdoor use, the 0/1-10V and triac dimmable drivers provide 5 years warranty and outstanding led dimming performance.

Features:
* Input Voltage: Universal 100VAC to 277VAC, 50/60Hz for Residential, Commercial, and Industrial Use
* Single Channel & Constant Voltage mode
* Output Voltage: 12Volt/24Volt/36Volt/48Volt
* Driver Type: Class 2 Class P
* Enclosure: LISTED Enclosure with input and output wire
* Dimming: Triac/ Phase-cut, PWM, 0/1-10V or MLV / ELV Resistance Dimmable Available
* Environmental: Dry and Damp
* Wiring Compartments with Knock-Outs for Clean and Easy Installation
* Current Limiting Overload Protection
* Flicker-Free
* Smooth Ripple Free Output Voltage
* IP67 Rated Enclosure for Indoor and Outdoor Use
* 5-Years Warranty
* UL/cUL CE FCC RoHS ENEC GS Listed, SELV, Type HL

Note:Any custom label/package/case is acceptable, provide OEM and ODM service

Input Voltage	100~277V AC 47~63Hz
Power Factor	PF≧0 98/115VAC, PF≧0 95/230VAC, PF≧0.9/277VAC, 80% with load
NO.	KSLP-60W
Output Voltage	12V/ 24V/ 36V/ 48V
Rated Current	5A/2.5A/1.67A/1.25A
Rated Power	60W
Ripple & Noise (max.)	200mVp-p/ 250mVp-p
Dimension(LWH)	3103224.5MM/ 12.21.250.96 inch

Show Details

Applications

The ultra slim class 2 led driver use low profile metal aluminum case with junction box makes the led dimming driver power solutions for LED strips, LED sign and landscape lighting.

NOW,GET MORE INFORMATIONS OF US !

Company Profile

Working Room

Specification:

Nearly ¥3 Million Is Spent On Certification, Just To Make Customers Trust Our Quality

Exhibition

Product packaging

1.Sample is available.

2.Shipping method: available for express DHL/UPS/FedEx/TNT, Land, Ocean and others.
3. for 60W power adapter : each one put in one small inner brown box, then 50 pcs put in one standard carton.

Package	Piece/Carton(pcs)	Piece Weight(KG)
OEM package	50	0.26
Dimension/Brown Box(mm)	Dimension/Carton(mm)	Gross Weight/Carton(KG)
1558535	455370175	14

FAQ
